[DETAIL]<br>DC12V-24V or AC220V Electric Brass Ball Valve, 3-wire 2-control Electric Ball Valve 2-way, 3-way DN15 DN20 DN25 DN32 DN40 DN50<br>Description：<br>• High Pressure Resistance :This brass motorized ball valve is designed to withstand high pressure, ensuring reliable performance and durability in various applications.<br>• Wide Temperature Range :With a medium temperature range, this valve is suitable for use in environments with a wide range of temperatures, making it versatile and adaptable.<br>• Three-Wire Electric Actuator :The three-wire electric actuator AC220V provides efficient and effective operation, enhancing the overall performance of the valve.<br>• Three-Way/Two-Way Functionality :The three-way/two-way functionality of this valve allows for flexible control over the flow of media, making it a valuable addition to any system.<br>• The maximum working pressure of the ball valve is 1.6MPa and the maximum working temperature is 90 ℃, which is very suitable for high pressure and high temperature projects.<br>• Simple connection: The ball valve connection is simple, fast and convenient, and it can be restored to the completely closed state after the power failure.Suitable media: Our ball valves can be used in cold water, hot water and 50% concentration solutions.Brass body: The valve body is made of brass and is not easily damaged.High protection level: The protection level of the ball valve is IP54, dustproof and waterproof, which can be used with confidence.<br>• Suitable media: Our ball valves can be used in cold water, hot water and 50% concentration solutions.<br>• Brass body: The valve body is made of brass and is not easily damaged.<br>• High protection level: The protection level of the ball valve is IP54, dustproof and waterproof, which can be used with confidence.<br>Feature:<br>• 3-Wire Two Control<br>• Way:2Ways /3Ways (3Ways is T type)<br>• Open/Close Time: 10s<br>• Maxmum Working Pressure: 1.6 MPa/232psi;<br>• Medium: Water, oil, non-corrosive non-flammable gas<br>• Voltage:DC12-24V 50/60 Hz AvailableAC220V 50/60 Hz Available<br>• Power: Max is 6W<br>• Torsion: 6N<br>• Operation: Motor and hand(with manual switch function)<br>• Life Time: 100000 times;<br>• Material: Brass,ABS plastic<br>• Seal material: EPDM & PTFE;<br>• Enviroment Temperature: 0°C~65°C in Celsius;<br>• Medium Temperature: -10°C~120°C in Celsiu<br>• Protect Class: IP54<br>Electric ball valve<br>Can be multi-angle installation flexibility<br>Good dust proof sealing<br>Ball valve structure analysis<br>The valve body is made of high quality brass for durability<br>Dimensional specification<br>Product shooting<br>2ways,3ways DC12V-24V or AC220V Motorized Brass Ball Valve,3 Wires 2 Control Electric Ball Valve DN15 DN20 DN25 DN32 DN40 DN50<br><br>[ATTRIBUTES]<br>- High-concerned chemical: None<br>- Actuator Mode: Without Manual And Instruction<br>- Structure: Ball<br>- High-concerned chemical: None<br>- Actuator Mode: Without Manual And Instruction<br>- Structure: Ball<br>- Port Size: DN15 DN20 DN25 DN32 DN40 DN50<br>- Media: water<br>- Material: Brass<br>- Temperature of Media: Normal Temperature<br>- Power: Solenoid<br>- Standard or Nonstandard: Standard<br>- Pressure: Low Pressure<br>- Brand Name: xmshxltd<br>- Is Smart Device: No<br>- Origin: Mainland China<br>- Certification: CE<br>- Voltage: AC220V,DC12V-24V<br>- Applicable industry: Environmental protection<br>- Structural form: 2way,3ways<br>- Control mode: Electric control type<br>- Form: Ball valve<br>- Mounting dimension: DN15 DN20 DN25 DN32 DN40 DN50<br>- Applicable temperature: 0-90°C<br>- Driving mode: Electric drive<br>- Valve body material: High quality brass<br>- Applicable medium: water
