1、 Automatically detects and converts incoming PC images to NTSC, PAL. 2、 Support high resolution PC input to SXGA (1920 @ 60Hz). 3、 Support resolution: 640x480 60 fps; 800x600 60 frames, 75 frames 60 frames 75 frames; 1024x768, 4、1280x720 60 frames; 1280x768 60 frames, 75 frames; 1280x1024 60 frames per second, 75 frames; 5、1360x768 60 fps; 1400x1050 60 fps; 1440x900 60 sheets; 6、60 frames per second, 60 frames for 1680x1050; 1600x1200; 1920x1080 for 60 frames per second; 7、1 frequency bandwidth 165MHz. 8、1 x VGA input port. 9、1 x BNC output port. 10、Introduction: 11、The VGA video scan converter is used to convert various images of the computer from 640x480 to 1920x1080, supporting NTSC or PAL video. It provides a composite output format. It is used for applications such as video conferencing, home theater, lecture room or TV computer image conversion. 12、Operational control and function: 13、 VGA input: VGA input port, connected to a PC or VGA generator. 14、 Audio input: L / R - Analog audio input port, connected to the computer's audio output port. 15、 Video output: BNC output, connected to the BNC interface display. 16、 Power: USB is connected to the power of the PC's USB port. 17、 PAL / NTSC format. 1*Converter 1*USB cable (standard type) 1*Operation manual ESD protected mannequin: ±8kV (air crevice discharge) ±4KV (contact discharge) Size: D*W*H: 66*55*20mm Weight: 40g Operating temperature: 0 C 40 C /°~°°~°F 104 F 32 Storage temperature: 20 C 60 C /°~°4°~°F F 140 Relative humidity: 90% RH (non-condensing)~ Power consumption: (maximum) 2.5W (maximum)
