SDR Receiver RTL2832U + R820T2 Chip with 1PPM TCXO, ADS-B Capable, Frequency Range 0.1 MHz–1.7 GHz This software-defined radio receiver converts signals received by the antenna into digital data and transmits them to computers, Android devices, and other compatible devices via USB interface. Compatible software processes the demodulated signal, displays the frequency spectrum, and enables adjustable reception bandwidth, signal recording, saving, and playback. Supports reception across 100 kHz–1.7 GHz and demodulation modes including AM, FM (NFM, WFM), CW, DSB, LSB, and USB. Suitable for shortwave single-sideband communications, FM broadcast, aviation band monitoring, ADS-B decoding, AIS signal reception, and meteor scatter observation. Features: - Built-in 1 ppm temperature-compensated crystal oscillator (TCXO) for improved frequency stability and accuracy - Low temperature drift (2 ppm initial deviation, 1 ppm over temperature range) - Enhanced thermal management for stable operation - RTL2832U + R820T2 chipset: R820T2 tuner offers improved sensitivity, lower noise floor, and higher signal-to-noise ratio compared to R820T; optimized performance up to ~1.5 GHz - Q-channel utilization on RTL2832U enables direct sampling reception from 100 kHz to 24 MHz - Full-band coverage from 100 kHz to 1.7 GHz Compatible with Windows XP/7/8/10, macOS, and Android. Specifications: - Type: SDR Receiver with Antenna - Dimensions: 71 × 43 × 19 mm (2.80 × 1.69 × 0.75 in) - Weight: 34 g - Color: Silver - Housing Material: Metal Package Includes: - 1 × RTL-SDR Receiver - 1 × Antenna Note: Color appearance may vary slightly due to lighting conditions and screen settings. Slight dimensional variations may occur due to manual measurement.
